本文地址:Linux源码 | EM能量模型 本文是基于linux kernel 5.15.41 能量模型(EM)<kernel/power/energy_model.c | 源代码 | v5.15.41>框架是一种驱动程序与内核子系统之间的接口。其中驱动程序了解不同性能层级的设备所消耗的功率,而内核子系统愿意使用该信息做出能量感知决策。EM框架管理着系统中各个设备提供的“性能域”,也就是频率功率的映射表,相关的能量感知算法可通过接口获取相应的设备的“性能域”,进行性能成本估算。 ![]() EM能量模型debug节点:/sys/kernel/debug/energy_model 目前在当前内核版本中,仅仅支持CPU device,CPU设备的em_perf_state中power<active_power | 源代码 | v5.15.41>和cost值计算公式如下:
1. energy_model结构<include/linux/energy_model.h | 源代码 | v5.15.41> struct em_perf_state {unsigned long frequency; unsigned long power; unsigned long cost; }; struct em_perf_domain { struct em_perf_state *table; int nr_perf_states; int milliwatts; unsigned long cpus[]; }; API函数接口 //获取相应device的em_perf_domain结构struct em_perf_domain *em_pd_get(struct device *dev); //通过cpu id获取CPU device的em_perf_domain结构 struct em_perf_domain *em_cpu_get(int cpu); //设备注册EM能量模型,这个接口是提供给设备使用 int em_dev_register_perf_domain(struct device *dev, unsigned int nr_states, struct em_data_callback *cb, cpumask_t *span, bool milliwatts); //设备注销EM能量模型,这个接口是提供给设备使用 void em_dev_unregister_perf_domain(struct device *dev); 2. em_dev_register_perf_domain将设备注册到em能量模型,这个接口是提供给驱动设备使用 // 将设备注册到em能量模型int em_dev_register_perf_domain(struct device *dev, unsigned int nr_states, struct em_data_callback *cb, cpumask_t *cpus, bool milliwatts) { unsigned long cap, prev_cap = 0; int cpu, ret; if (!dev || !nr_states || !cb) return -EINVAL; /* * Use a mutex to serialize the registration of performance domains and * let the driver-defined callback functions sleep. */ mutex_lock(&em_pd_mutex); if (dev->em_pd) { ret = -EEXIST; goto unlock; } //判断是否是cpu设备,dev->bus是否是虚拟总线cpu_subsys if (_is_cpu_device(dev)) { if (!cpus) { dev_err(dev, "EM: invalid CPU mask\n"); ret = -EINVAL; goto unlock; } for_each_cpu(cpu, cpus) { //返回CPU的性能域 if (em_cpu_get(cpu)) { dev_err(dev, "EM: exists for CPU%d\n", cpu); ret = -EEXIST; goto unlock; } /* * All CPUs of a domain must have the same * micro-architecture since they all share the same * table. */ // 获取cpu的capacity,当前cpu算力和上一个算力不相等 cap = arch_scale_cpu_capacity(cpu); if (prev_cap && prev_cap != cap) { dev_err(dev, "EM: CPUs of %*pbl must have the same capacity\n", cpumask_pr_args(cpus));//printf输出cpumask ret = -EINVAL; goto unlock; } prev_cap = cap; } } // 创建em_perf_domain ret = em_create_pd(dev, nr_states, cb, cpus); if (ret) goto unlock; dev->em_pd->milliwatts = milliwatts; //创建em能量模型对应的设备debug接口:/sys/kernel/debug/energy_model em_debug_create_pd(dev); dev_info(dev, "EM: created perf domain\n"); unlock: mutex_unlock(&em_pd_mutex); return ret; } EXPORT_SYMBOL_GPL(em_dev_register_perf_domain); // 创建em_perf_domain static int em_create_pd(struct device *dev, int nr_states, struct em_data_callback *cb, cpumask_t *cpus) { struct em_perf_domain *pd; struct device *cpu_dev; int cpu, ret; if (_is_cpu_device(dev)) { //创建em_perf_domain对象 pd = kzalloc(sizeof(*pd) + cpumask_size(), GFP_KERNEL); if (!pd) return -ENOMEM; //copy cpumask cpumask_copy(em_span_cpus(pd), cpus); } else { // 非CPU设备 pd = kzalloc(sizeof(*pd), GFP_KERNEL); if (!pd) return -ENOMEM; } // 创建性能映射表,频率和功耗映射关系,计算cost ret = em_create_perf_table(dev, pd, nr_states, cb); if (ret) { kfree(pd); return ret; } if (_is_cpu_device(dev)) for_each_cpu(cpu, cpus) { cpu_dev = get_cpu_device(cpu); cpu_dev->em_pd = pd; } dev->em_pd = pd; return 0; } // 创建性能映射表 static int em_create_perf_table(struct device *dev, struct em_perf_domain *pd, int nr_states, struct em_data_callback *cb) { unsigned long power, freq, prev_freq = 0, prev_cost = ULONG_MAX; struct em_perf_state *table; int i, ret; u64 fmax; table = kcalloc(nr_states, sizeof(*table), GFP_KERNEL); if (!table) return -ENOMEM; // 创建功耗和频率映射表 /* Build the list of performance states for this performance domain */ for (i = 0, freq = 0; i < nr_states; i++, freq++) { /* * active_power() is a driver callback which ceils 'freq' to * lowest performance state of 'dev' above 'freq' and updates * 'power' and 'freq' accordingly. */ // 回调设备的power计算函数,获取功耗和频率 ret = cb->active_power(&power, &freq, dev); if (ret) { dev_err(dev, "EM: invalid perf. state: %d\n", ret); goto free_ps_table; } /* * We expect the driver callback to increase the frequency for * higher performance states. */ // 新增的freq必须比上一个freq大,递增 if (freq <= prev_freq) { dev_err(dev, "EM: non-increasing freq: %lu\n", freq); goto free_ps_table; } /* * The power returned by active_state() is expected to be * positive and to fit into 16 bits. */ if (!power || power > EM_MAX_POWER) { dev_err(dev, "EM: invalid power: %lu\n", power); goto free_ps_table; } table[i].power = power; table[i].frequency = prev_freq = freq; } //计算的cost,cost = max_freq * power / frequency /* Compute the cost of each performance state. */ fmax = (u64) table[nr_states - 1].frequency; for (i = nr_states - 1; i >= 0; i--) { unsigned long power_res = em_scale_power(table[i].power); table[i].cost = div64_u64(fmax * power_res, table[i].frequency); if (table[i].cost >= prev_cost) { dev_dbg(dev, "EM: OPP:%lu is inefficient\n", table[i].frequency); } else { prev_cost = table[i].cost; } } pd->table = table; pd->nr_perf_states = nr_states; return 0; free_ps_table: kfree(table); return -EINVAL; } 3. em_pd_get获取相应device的em_perf_domain结构,主要是给相关能量感知算法去调用,如:EAS、IPA。 struct em_perf_domain *em_pd_get(struct device *dev){ if (IS_ERR_OR_NULL(dev)) return NULL; return dev->em_pd; } 4. em_cpu_get通过cpu id获取相应的cpu device的em_perf_domain结构,主要是给相关能量感知算法去调用,如:EAS、IPA。 struct em_perf_domain *em_cpu_get(int cpu){ struct device *cpu_dev; cpu_dev = get_cpu_device(cpu); if (!cpu_dev) return NULL; return em_pd_get(cpu_dev); } EXPORT_SYMBOL_GPL(em_cpu_get); 5. em_cpu_energy计算在当前性能下cpu消耗的power static inline unsigned long em_cpu_energy(struct em_perf_domain *pd,unsigned long max_util, unsigned long sum_util, unsigned long allowed_cpu_cap) { unsigned long freq, scale_cpu; struct em_perf_state *ps; int i, cpu; if (!sum_util) return 0; /* * In order to predict the performance state, map the utilization of * the most utilized CPU of the performance domain to a requested * frequency, like schedutil. Take also into account that the real * frequency might be set lower (due to thermal capping). Thus, clamp * max utilization to the allowed CPU capacity before calculating * effective frequency. */ cpu = cpumask_first(to_cpumask(pd->cpus)); // 获取CPU归一化的capacity scale_cpu = arch_scale_cpu_capacity(cpu); ps = &pd->table[pd->nr_perf_states - 1]; max_util = map_util_perf(max_util); // allowed_cpu_cap会限制max_util max_util = min(max_util, allowed_cpu_cap); // 获取通过max_util获取对应的最大freq freq = map_util_freq(max_util, ps->frequency, scale_cpu); /* * Find the lowest performance state of the Energy Model above the * requested frequency. */ // 找到最大freq对应的em table for (i = 0; i < pd->nr_perf_states; i++) { ps = &pd->table[i]; if (ps->frequency >= freq) break; } /* * The capacity of a CPU in the domain at the performance state (ps) * can be computed as: * 通过频率比例,计算当前性能下需要的cpu的capacity * scale_cpu * ps->freq * ps->cap = -------------------- (1) * cpu_max_freq * * So, ignoring the costs of idle states (which are not available in * the EM), the energy consumed by this CPU at that performance state * is estimated as: * 通过util比例,计算在当前性能下cpu消耗的power * ps->power * cpu_util * cpu_nrg = -------------------- (2) * ps->cap * * since 'cpu_util / ps->cap' represents its percentage of busy time. * * NOTE: Although the result of this computation actually is in * units of power, it can be manipulated as an energy value * over a scheduling period, since it is assumed to be * constant during that interval. * * By injecting (1) in (2), 'cpu_nrg' can be re-expressed as a product * of two terms: * * ps->power * cpu_max_freq cpu_util * cpu_nrg = ------------------------ * --------- (3) * ps->freq scale_cpu * * The first term is static, and is stored in the em_perf_state struct * as 'ps->cost'. * * Since all CPUs of the domain have the same micro-architecture, they * share the same 'ps->cost', and the same CPU capacity. Hence, the * total energy of the domain (which is the simple sum of the energy of * all of its CPUs) can be factorized as: * * ps->cost * \Sum cpu_util * pd_nrg = ------------------------ (4) * scale_cpu */ // 计算在当前性能下cpu消耗的power return ps->cost * sum_util / scale_cpu; } 本文地址:Linux源码 | EM能量模型 |
